6418 Marine Jack | A-Frame | 1,000 lb. #16418 Marine Jack | A-Frame | 1,000 lb. #2

6418 Marine Jack | A-Frame | 1,000 lb.

Part Number 22530
Price: $84.99
Manufactured in the USA3 Year Limited Warranty
  • Dutton-Lainson® A-frame marine tongue jack for boat and other trailer applications
  • 1,000 lb. capacity
  • 15" total travel
  • 29-3/4" maximum tongue height
  • Side wind handle with extra heavy screw drive and ergonomic handle grip
  • Removable foot or wheel sold separately
  • Zinc plated TUFFPLATE® finish for additional rust resistance and longer life
  • Includes mounting hardware
  • Made in the U.S.A.

When hitching and unhitching loaded trailers, D-L heavy duty tongue jacks are real back savers. These easy-to-install, smooth operating jacks can be mounted in a variety of ways on various sizes of trailer tongues. They reduce the physical effort required to maneuver a loaded trailer into hitching position or removing the trailer from a vehicle. All models are made from heavy gauge steel for strength and durability. Features include:

  • Totally enclosed outer tube helps protect miter gears and heavy duty Acme screw from sand and dirt
  • Fits square tongues up to 3" x 5"
  • 2-1/2" diameter mounting hole in swivel bracket fits most other brands of mounting hardware
  • Floating miter gears allow for proper clearance and easier operation
  • Tough polypropylene wheels or zinc plated foot
  • Ergonomic molded handle grip with textured surface
Owner's Manual
