6400, 6414, 6418 & 6709

Price

Part Number 6400

6400, 6414, 6418 & 6709

For Swivel Mount & Rigid Mount Side Crank Tongue Jack Models: 6400, 6414, 6418 & 6709

- A.....5224373 - MITER GEAR KIT (DATE 3397-PRESENT) (+$12.99)

- A.....5224472 - MITER GEAR KIT (DATE 4296 TO 3297) (+$12.99)

- A.....5224423 - MITER GEAR KIT (PRIOR TO 4296) (+$16.99)

- B.....5224431 - 6804 CLAMP & BOLT KIT (+$9.99)

- C.....5224407 - 6806 6" WHEEL ASSY (STANDARD DUTY) (+$8.99)

- C.....5224118 - 6805 6" WHEEL ASSY (HEAVY DUTY) (+$10.99)

- D.....5226360 - 6" WHEEL BRACKET ASSY (+$15.42)

- D.....5226386 - 8" WHEEL BRACKET ASSY (+$21.16)

- F.....5224100 - 6807 8" WHEEL ASSY (+$15.99)

- H.....5224258 - SWIVEL KIT (FOR 1/2" HANDLE) (+$11.99)

- H.....5224449 - SWIVEL KIT (FOR 3/8" HANDLE) (+$11.99)

- J.....5224266 - SWIVEL KIT (FOR 1/2" HANDLE) (+$10.99)

- J.....5224829 - SWIVEL KIT (FOR 3/8" HANDLE) (+$9.99)

- P.....5225412 - REMOVABLE FOOT & CLEVIS PIN (+$19.99)

- Q.....5224142 - CASTER WHEEL (+$25.99)

- R.....205389 - CARRIAGE BOLT, 3/8-16 X 1" (+$0.42)

- T.....403283-PL - CLOVER LEAF WASHER (+$2.04)

- U.....403282 - SWIVEL BRACKET WASHER (4 BOLT) (+$1.53)

- W.....205285 - FLANGED LOCKNUT, 3/8-16 (+$0.36)

- X.....5224464 - JACK HANDLE ASSY W/ PIN (+$11.99)

- Y.....5224498 - SWIVEL HANDLE 3/8" DIA. KIT (+$5.99)

- Y.....5224548 - SWIVEL HANDLE 1/2" DIA. KIT (+$7.99)

- CC....403411 - WELD-ON BRACKET, 3/8" HANDLE (+$7.31)

- CC....5226717 - WELD-ON BRACKET, 1/2" HANDLE (+$9.99)

- DD....203916 - RETAINING RING (+$1.74)

- FF....207357 - HARDENED FLAT WASHER (+$0.53)

- GG....207356 - PLASTIC THRUST WASHER (+$0.23)

- HH....205043 - HEX BOLT,3/8-16 X 1" (+$0.59)

- JJ....205042 - LOCKWASHER, 3/8" (+$0.82)

- KK....205050 - HEX NUT, 3/8-16 (+$0.63)

- LL....5227533 - 6610 WELD-ON SWIVEL BRACKET (+$9.99)

- MM....5223540 - END CAP (+$1.99)

- NN....403563 - WELD-ON STRAP (+$7.52)

- RR....5221924 - 4-1/2" CHANNEL MOUNT PLATE (+$15.43)

- RR....5221932 - 5-1/2" CHANNEL MOUNT PLATE (+$18.41)

- RR....5221940 - 6-1/2" CHANNEL MOUNT PLATE (+$19.49)

- SS....205372 - CARRIAGE BOLT, 3/8-16 X 1-1/4" (+$0.46)

Price

6460A & 6461

Price

6800, 6850 & 6851

Price

6814, 6816, 6817 & 6820

Price

6816

Price

SA5000DC & SA7000DC
(W & W/O REMOTE)

Price

Part Number A-SA5000DC-1

SA5000DC & SA7000DC
(W & W/O REMOTE)

For Electric Winch Models: SA5000DC, SA5015DC, SA7000DC, SA7015DC WITH CLUTCH

- A.....205191 - Retaining Ring (2) (+$0.63)

- B.....204012 - Bushing (+$1.47)

- C.....304813 - Drive Shaft Assembly (+$10.86)

- D.....204009 - Bushing (+$1.47)

- E.....204703 - 56T Gear (+$20.48)

- F.....304412 - Handle Assembly (+$9.99)

- G.....404557 - Base Spacer (+$3.53)

- H.....404922 - Base (+$26.65)

- K.....5703210 - Brake Spring Replacement Kit (+$12.60)

- N.....205192 - Locknut, 7/16-20 (+$1.20)

- P.....404517 - Clutch Stud (+$5.46)

- Q.....5703194 - Thrust Bearing Replacement Kit (Includes Item X) (+$12.66)

- R.....5703178 - Clutch Handle Replacement Kit (Includes Items W, X, AQ & AR) (+$8.27)

- S.....306100 - CLUTCH GEAR ASSY (DATE CODE 2508 TO PRESENT) (+$19.26)

- T.....205200 - Finger Spring Washer (+$1.20)

- U.....306102 - 120T GEAR ASSY (DATE CODE 2508 TO PRESENT) (+$36.48)

- V.....404518 - Clutch Handle Nut (+$5.29)

- W.....204721 - Clutch Spring Keeper (+$2.79)

- X.....204770 - 'O' Ring (+$0.82)

- Y.....404562 - Front Place Spacer (3) (+$1.47)

- Z.....404553 - Front Plate (+$15.14)

- AA....205238 - Screw-1/4-20x5/8 (3) (+$0.63)

- AB....205193 - Locknut, 10-32 (2) (+$0.74)

- AC....304407 - Brake Disc Assembly (+$18.40)

- AD....404522 - Motor Pinion (+$4.12)

- AE....205135 - 'E' Ring (+$0.53)

- AF....404559 - Reel Shaft (+$4.24)

- AG....204468 - Retaining Ring (+$0.82)

- AH....205337 - Screw, 1/4-20x3/8 (2) (+$0.53)

- AJ....304617 - CABLE CLAMP KIT (+$2.39)

- AK....205338 - Screw, 1/4-20x3/4 (2) (+$0.36)

- AL....304812 - Reel Assembly (+$38.51)

- AN....204713 - Cover Plug (+$0.82)

- AP....404563 - COVER (SA5000-SA7000) (+$30.39)

- AP....404983 - COVER (SA5015-SA7015) WITH REMOTE) (+$26.10)

- AQ....204712 - Clutch Handle (+$3.74)

- AR....205196 - Screw, #4 (2) (+$0.63)

- AS....204661 - Clutch Spring (+$3.44)

- AU....5240692 - CABLE & HOOK- 3/16" X 20' (SA5000DC/SA5015DC) (+$22.99)

- AU....5240445 - CABLE & HOOK- 3/16" X 50' (SA7000DC/SA7015DC) (+$35.99)

- AV....205190 - Screw, 1/4-20 x 1" (2) (+$0.82)

- AW....206624 - Top Decal (Not Shown) (+$11.97)

- AW....206631 - TOP DECAL REMOTE (NOT SHOWN) (+$11.97)

- AY....204729 - D-L Decal (Not Shown) (+$1.24)

- AZ....204731 - Clutch Decal (Not Shown) (+$0.67)

- BA....304349 - Motor Assembly (+$153.96)

- BA....304973 - MOTOR ASSY FOR REMOTE (+$153.15)

- BB....5240494 - SWITCH ASSEMBLY & HARNESS (SA5000DC/SA7000DC) (+$59.99)

- BC....205018 - Cap Screw, 1/4-20x3/8 (+$0.82)

- BE....206225 - Hex Nut (+$0.63)

- BF....304025 - Breaker Assembly (+$21.61)

- BG....5703129 - Pocket Plate Repair Kit (+$8.99)

- BH....5240411 - Replacement Switch Kit (+$27.99)

- BJ....5240973 - 6172 REMOTE (SA5015DC/SA7015DC) (+$69.99)

- BJ....206431 - IN/OUT ROCKER SWITCH ONLY (+$20.31)

- BK....5241518 - WIRING HARNESS, (SA5015DC/SA7015DC) (+$59.99)

- BL....304971 - RELAY ASSY FOR REMOTE (+$56.36)

- BM....304917 - PIGTAIL FOR REMOTE (+$31.69)

- BN....206670 - STRAIN RELIEF BUSHING (+$0.42)

- BP....206055 - CONNECTOR HOUSING FOR REMOTE (+$7.94)

- BQ....204959 - THREAD CUTTING SCREW (+$0.55)

- BR....205025 - THREAD FORMING SCREW (+$0.55)

- DA....5240270 - PULLEY BLOCK & HOOK (SA7000DC/SA7015DC) (+$26.99)
